MX-SL600W
SMX
High brightness short throw projector for immersive, education, and commercial applications.
This 6000 lumens WXGA 3LCD laser projector is designed for immersive projection, classrooms, and business environments. With a 0.44:1 short throw ratio, it can project large images in limited spaces while reducing shadows and improving interaction.
The projector supports 4K signal input, ensuring compatibility with modern content sources while maintaining stable performance and long lifespan up to 20,000 hours.
6000 Lumens Brightness – Bright image in ambient light
WXGA Resolution – Cost-effective and reliable
4K Input Support – Compatible with 4K content sources
Short Throw 0.44:1 – Large screen at short distance
3LCD Technology – Accurate color reproduction
Laser Light Source – 20,000 hours lifespan
Immersive wall projection
Education & classrooms
Interactive environments
Museums & exhibitions
Meeting rooms
Item | Specification |
|---|---|
Brightness | 6000 Lumens |
Resolution | WXGA (1280×800) |
Display Technology | 3LCD |
Light Source | Laser |
Throw Ratio | 0.44:1 |
4K Input | Supported |
Contrast Ratio | 5,000,000:1 |
Lifespan | 20,000 Hours |
Screen Size | 55–300 inch |
A 6000 lumen projector provides high brightness for environments with ambient light. Short throw design minimizes shadows and enables flexible installation.
With 4K input compatibility, this projector can handle high-resolution content sources, making it future-ready for modern AV systems.
Contact SMX for pricing, OEM solutions, and expert support.
| 2Model | MX-SL600W | |
| Brightness(Lumen) | 6000 | |
| Overall Spec | ||
| Panel | Display Panel | 3x0.64” with MLA |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WXGA (1280 x 800) | |
| Light source Life time | Normal mode | 20000hrs |
| ECO1 mode | 30000hrs | |
| Lens | Lens Vendor | RICOH |
| Projection Lens | F | F1.6 |
| f | 6.39mm | |
| Zoom/Focus | Manual | |
| Throw Ratio | 0.44:1 | |
| Screen size | 55-300inch | |
| CR | Contrast Ratio (FOFO) | 5000000:1 |
| Noise | Noise(dB) | 37dB (Normal) / 27dB (ECO) |
| Uniformity | Uniformit | 80% |
| AR | Aspect Ratio | Native:16:10 / Compatible: 4:3/16:9 |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI 1.4B(IN) | *2 | |
| USB-A | *1 | |
| USB-B | *1(Display) | |
| RJ45 | *1 (Display) | |
| HD BaseT | *1 (Optional) | |
| Audio in (mini jack,3.5mm) | *1 | |
| Output | VGA | *1 |
| Audio out (mini-jack,3.5mm) | *1 | |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) | |
| USB-B | *1 (For upgrade) | |
| General Spec | ||
| Audio | Speaker | 16W*1 |
| Dust filter | W/Filter | |
| Filter Life time | 8000h | |
| Other Functions | ||
| Keystone | Keystone Correction (Lens@center) | V: ±15° H: ±15° Pincushion/Barrel Correction 6 Corner correction 4 Corner Correction Grid image tune |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-- AMX Discovery | Yes | |
| LAN Control-- PJ Link | Yes | |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 24~85Hz | |
| Others | 360° Projection | Yes |
| Dimension&Weight | ||
| MAX Dimensions (WxHxD mm) | 405(W)×404(D)×164(H) | |
| Net. Weight (KG) | 8.1kg | |
| Packaging B (WxHxD mm) | 510(W)×498(D)×260(H) | |
| Gross. Weight (KG) | ~10.4KG | |
| Accessory | ||
| Manual Languages | Chinese,English | |
| Standard Accessaries | Power cord / HDMI / Remote control | |
