5500 Lumens WUXGA 3LCD Laser Projector for Home Cinema with 4K Input | SMX

5500 Lumens High Brightness
WUXGA 1920×1200 Resolution
3LCD True Color Technology
4K Input Compatible (HDMI)
5,000,000:1 Dynamic Contrast
RICOH Lens with Lens Shift
360° Projection & Geometry Correction
20,000–30,000 Hours Laser Lifespan

Availability:

Quantity:



Inquire Add to Basket

Model:
MX-STD5500UG
Brand:
SMX

5500 Lumens WUXGA 3LCD Laser Projector

Professional home cinema laser projector with 4K input support and immersive viewing performance.

5500 Lumens WUXGA 3LCD Laser Projector for Home Cinema

The SMX MX-STD5500UG is designed for home cinema, gaming, and immersive projection environments.

With 5500 lumens of brightness, WUXGA resolution, and 3LCD technology, it delivers vivid color and clear images even in rooms with ambient light.

The projector supports 4K input through HDMI while maintaining smooth Full HD image performance for movies, presentations, and entertainment.

Key Features

5500 Lumens Brightness – Clear projection in bright rooms
WUXGA 1920×1200 – Sharp and detailed Full HD image quality
3LCD Technology – Accurate color reproduction (Learn More)
4K Input Compatible – Supports HDMI 4K signal input
RICOH Lens – Professional optical performance
Lens Shift & Geometry Correction – Flexible installation
360° Projection – Suitable for immersive projection systems
Laser Light Source – Up to 30,000 hours lifespan

Applications

5500 lumen laser projector for meeting room.webp

Specifications

Item	Specification
Brightness	5500 Lumens
Resolution	WUXGA (1920×1200)
Display Technology	3LCD
Contrast Ratio	5,000,000:1
Throw Ratio	1.2–2.0:1
Lens	RICOH Lens
Input	HDMI ×2 / VGA ×1
Speaker	16W Built-in Speaker
Light Source	Laser
Lifespan	20,000–30,000 Hours

Upgrade Your Home Cinema Experience

Contact SMX for pricing, OEM/ODM services, and professional projector solutions.

Get Quote

Download Datasheet

All Products

	Model No.	MX-STD5500UG
Key parts
	Brightness(Lumen)	5500
	Resolution	WUXGA
	Panel	SONY 0.64"
	Lens Maker	RICOH Lens
	Light source	NICHIA LASER
Overall Spec
Light source Life time	Normal mode	20000hrs
Light source Life time	ECO mode	30000hrs(TBD)
Projection Lens	Lens Vendor	RICOH
	F	1.5~2.08
	f	17.2~27.7mm
	Zoom/Focus	Manual
	Throw Ratio	1.2~2.0:1
	Zoom Ratio	1.6x optics
	Screen size	30-300 inch
	Lens shift	V: +35%~0%(TBD)
CR	Dynamic Contrast Ratio (FOFO)	5000,000:1
Noise	Noise(dB)	TGT: 37dB(Normal) 27dB(ECO1)
Uniformity	Uniformity	80%
AR	Aspect Ratio	16:10 (Standard)/4:3(Compatible)
Terminal(I/O port)
Input	VGA	*1
	HDMI	*2
	Video	*1
	Audio in (mini jack,3.5mm)	*1
	Audio in (RCA×2) <Audio L/R>	*1
	USB-A	*1
	USB-B	*1(Display)
	RJ45	*1(Display)
Output	VGA	*1
Output	Audio out (mini-jack,3.5mm)	*1
Control	RS232	*1
	RJ45	*1 (Control)
	USB-B	*1
	LAN	*1
General Spec
Audio	Speaker	16W*1
Dust filter		W/Filter
Filter Life Time		7300h(TBD)
Power Consumption	Power Requirements	100~240V@ 50/60Hz
Power Consumption	ECO Standby Mode Power Consumption	<0.5W
Temp.&Humidity	Operating Temp.	5 to 40°C
	Operating Thumidity.	20-80%
	Storage Temp.	-10 to 50°C
	Storage Humidity.	10-85%
	High altitude	1700-3000m
Other Functions
Keystone	Keystone Correction (Lens@center)	V: ±30° H: ±30° Pincushion/Barrel Correction, 4 corners 6 Corner, Geometry correction, Grid image tune
OSD	Languages	26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazakh, Vietnamese, Thai, Farsi
LAN Control	LAN Control -RoomView (Crestron)	Yes
	LAN Control-- AMX Discovery	Yes
	LAN Control-- PJ Link	Yes
Scanning Frequency	H-Synch Range	15~100KHz
Scanning Frequency	V-Synch Range	24~85Hz
Display Resolution	Computer Signal Input	VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA,4K@30Hz
Display Resolution	Video Signal Input	480i, 480p, 576i, 576p, 720p, 1080i and 1080p
SW setting	Auto Setup	INPUT SEARCH, AUTO PC, Auto Keystone
	Blank	Yes
	Suspend	Yes (5 minutes, no signal as default)
	Picture mode	Dynamic, Standard, Cinema, Colorboard, Blackboard(Green)
	Cooling time	5s
	Closed caption	Yes
	Auto Ceiling	Yes
	D-Zoom	1~19
Others	360° projection	Yes
Dimension&Weight
	MAX Dimensions (WxDxH mm)	390294127
	Net. Weight (KG)	5Kg
Accessory
	Manual Languages	Chinese, English
	Standard Accessaries	Power cord, Remote control, HDMI Cable
