SMX 5200 Lumen Short Throw Laser Projector – 4K HDR Home Theater & Gaming

  • 5200 Lumens High Brightness
  • True 4K HDR Resolution
  • Short Throw for Compact Spaces
  • Laser Light Source, Long Lifespan
  • Perfect for Home Theater & Gaming
Availability:
Quantity:
Inquire Add to Basket

  • MX-LK5200ST

  • SMX


SMX 5200 Lumen Short-Throw Laser Projector


Stunning 4K HDR visuals for home theater, gaming, and immersive cinematic experiences.



5200 Lumens 4K Short Throw Laser Projector


Short Throw Laser Projector for Home Theater & Gaming


The SMX 5200 Lumen Short-Throw Laser Projector delivers incredible 4K HDR image quality, perfect for small- to medium-sized rooms. Compact short-throw design ensures a large image from a short distance, ideal for home theaters and gaming setups.

Laser technology provides long-lasting, vivid colors and high brightness for all lighting conditions.


Key Features


  • 5200 Lumens Brightness - Clear images even in ambient light

  • Short Throw Lens - Big screen in a limited space

  • 4K HDR Resolution - Stunning image detail

  • Laser Technology - 20,000 hours lifespan

  • Versatile Connectivity - Multi-port

  • Immersive Audio - Built-in speakers

  • Flexible Installation - Keystone Correction



home-theater-4k laser projector



Speaker

4K Home Theater Laser Projector Short throw Projector with speaker



Laser Light Source for Long Lifetime

Short Throw 4K Laser Projector Home Cinema



360° Projection

360 projection 4K Home Cinema Projector Laser Projector



Keystone Correction

Home Theater 4K laser Projector Short Throw Projector



Specifications

Feature Specification
Brightness 5200 Lumens
Resolution 4K HDR
Display Technology DLP Laser
Light Source Laser
Lifespan 20,000 Hours
Short Throw Yes
Input Lag Low, Gaming Optimized
Installation Ceiling & Table Top


Applications


  • Home Theater

  • Gaming Room

  • Small Auditorium

  • Media Rooms

  • Educational Presentations



Get Your SMX 5200 Projector

Contact SMX today for pricing, OEM services, or engineering support.

Request a Quote

OEM Project

All Products



Model

Model No.MX-LK5200ST
Brightness(Lumen)5200
Resolution4K
Overall Spec
PanelDisplay Panel3x0.64" with MLA
Display TechnologyLiquid Crystal Display
Light source LifetimeLight SourceLaser
Normal mode20000hrs
ECO mode30000hrs
Projection LensLens VendorRICOH Lens
F1.6
f6.39mm
Zoom/FocusManual
Throw Ratio0.44:1
Screen size50-300inch
CRDynamic Contrast Ratio5000,000:1
NoiseNoise(dB)40dB(Normal)
 30dB(ECO)
UniformityUniformity80%
ARAspect RatioNative:16:9
Compatible: 4:3/16:10
Terminal(I/O port)
InputHDMI  (2.0IN)*2
USB-A*2
RJ45*1
HD BaseT*1(Optional)
OutputAudio portS/PDIF*1
Audio out
(mini-jack,3.5mm）		*1
ControlRS232C*1
RJ45*1   (Control)
General Spec
AudioSpeaker16W*1
Dust filterW/Filter
Filter Life time7000h
Power ConsumptionPower Requeirements100~240V@50/60Hz
Power Consumption
 (Normal) (Max)		330
Power Consumption
 (ECO1) (Max)		190
ECO Standby Mode
Power Consumption		<0.5W
Temp.&HumidityOperating   Temp.0   to 40°C
Operating humidity.20-80%
Storage Temp. -10 to 50°C
Storage humidity.10-85%
High altitude0-3000m
Other Functions
KeystoneKeystone Correction
(Lens@center)		V: ±15° H：±15°
4 corner
OSDLanguagesEnglish,Simplified Chinese
LAN ControlLAN Control--PJ LinkYes
Scanning FrequencyH-Synch Range15~100KHz
V-Synch Range24~85Hz
Display ResolutionComputer Signal Inputup to 4K60Hz
SW settingD-ZoomYES（HDMI）
laser modeNormal/ECO
Light source
brightness adjustment		50-100%
High altitudeYes
Auto CeilingYes
HDR10Yes
Standby modeNormal/ECO
Others360° projectionYes
Dimension&Weight

Product size
(WxDxH mm)		390*319*144;
with len
Net. Weight (KG)5.5Kg
Packing Size
(WxDxH mm)		492*443*239
Gross. Weight (KG)~7Kg
Accessory

Manual LanguagesChinese,English
Standard AccessariesPower cord , Remote control, HDMI Cable


download SMX 4800-5200 Lumen 4K Laser Projector Short Throw.pdf
