8200 Lumen WUXGA Laser Projector | DLP Installation Projector for Large Venues – SMX

Home » Products » DLP Laser Projectors » Standard Throw Projectors » 8200 Lumen WUXGA Laser Projector | DLP Installation Projector for Large Venues – SMX

SMX 8200 Lumen WUXGA DLP Laser Projector

Share to:

8200 Lumen WUXGA Laser Projector | DLP Installation Projector for Large Venues – SMX

⭐ Key Selling Points

8200 Lumens High Brightness – Clear images even in bright environments
WUXGA Full HD Resolution (1920×1200) – Ultra-sharp and detailed visuals
Laser Light Source (20,000–30,000 hrs) – Maintenance-free & long lifespan
5,000,000:1 High Contrast Ratio – Deep blacks and vivid colors
Flexible Installation (Lens Shift + 360° Projection)

Availability:

Quantity:



Inquire Add to Basket

Model:
MX-DL820U
Brand:
SMX

8200 Lumens WUXGA Laser Projector

Professional DLP Installation Projector for Large Venues

✔ 8200 Lumens High Brightness

✔ WUXGA 1920×1200 Resolution

✔ 30,000 Hours Laser Lifespan

✔ 5,000,000:1 Contrast Ratio

✔ 360° Flexible Installation

Get a Quote

Ideal Applications

Conference Rooms
Auditoriums
Churches
Exhibition Halls

Key Features

High Brightness: 8200 lumens ensures clear projection even in bright environments.
WUXGA Resolution: 1920×1200 delivers sharp and detailed visuals.
Laser Technology: Up to 30,000 hours lifespan with low maintenance cost.
Flexible Installation: Supports 360° projection and lens shift.
High Contrast: 5,000,000:1 contrast ratio for vivid image quality.

Applications

Meeting rooms & boardrooms
Corporate presentation spaces
Auditoriums
Exhibitions & trade shows
Education & lecture halls

Technical Specifications

Brightness	8200 Lumens
Resolution	WUXGA (1920×1200)
Light Source	Laser
Lifetime	30,000 Hours
Contrast Ratio	5,000,000:1
Projection	360° Supported
Inputs	HDMI / VGA / USB / LAN

Why Choose Us

OEM / ODM Supported
15,000 Units Monthly Capacity
Strict Quality Control
Global Export Experience

FAQ

What is WUXGA resolution?
WUXGA (1920×1200) provides sharper images than Full HD.

Is laser projector better than lamp?
Yes, laser projectors offer longer lifespan and lower maintenance.

Ready to Upgrade Your Projection Solution?

Contact Us Now

Key Parts
	Model No.	MX-DL820U
	Resolution	1080P
	Brightness(Ansi Lumen)	8200
Overall Spec
Panel	Display Panel	0.65" DMD
	Display Technology	DLP
	Native Resolution	1080P (1920 x 1080)
Light source Life time	Normal mode	20,000hrs
Light source Life time	ECO1 mode	30,000hrs
Projection Lens	F	2.4
	f	15.3mm-24.6mm
	Zoom/Focus	Manual
	Throw Ratio	1.03(wide)~1.68(tele)
	Zoom Ratio	1.63
	Screen size	80-300inch
	Lens Shift	V:＋37%～-10% H:±8%
CR	Contrast Ratio	5,000,000:1
Noise	Noise(dB)	39dB(Normal) ; 36dB(ECO）
Uniformity	Uniformity	95%
AR	Aspect Ratio	Native:16:9 Compatible: 4:3/16:10
Terminal(I/O port)
Input	VGA	*2
	HDMI 1.4B(IN)	*2
	HD BaseT	*1(Optional)
	Video	*1
	Audio L (RCA)	*1
	Audio R (RCA)	*1
	Audio in (mini jack,3.5mm）	*1
Output	VGA	*1
Output	Audio out (mini-jack,3.5mm)	*1
Control	RS232	*1
	RJ45	*1 (Control)
	USB-B	*1 (For upgrade)
	USB (Type A) only supports 5V	*1
General Spec
Audio	Speaker	10W*1
Power Consumption	Power Requirements	100~240V@ 50/60Hz
	Power Consumption (Normal) (Max)	670
	Power Consumption (ECO1) (Max)	520
	ECO Standby Mode Power Consumption	<0.5W
Temp.&Humidity	Operating Temp.	0m≤Altitude≤1700m, Ambient0℃~50℃
	Operating Temp.	1700m＜Altitude＜3000m, Ambient 0℃~40℃
	Operating Thumidity.	20-85%
	Store Temp.	-10 to 50°C
	High altitude	0~3000m
Other Functions
Keystone	Keystone Correction (Lens@center)	V: ±30° 4 Corner Correction
OSD	Languages	26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazakh, Vietnamese, Thai, Farsi
LAN Control	LAN Control-RoomView (Crestron)	Yes
	LAN Control-- AMX Discovery	Yes
	LAN Control-- PJ Link	Yes
Scanning Frequency	H-Synch Range	15~100KHz
Scanning Frequency	V-Synch Range	24~85Hz
Display Resolution	Computer Signal Input	VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA
Display Resolution	Video Signal Input	480i, 480p, 576i, 576p, 720p, 1080i and 1080p
SW setting	Auto Setup	INPUT SEARCH, AUTO PC, Auto Keystone
	Blank	Yes
	Suspend	Yes(5 minutes no signal as default)
	Picture mode	Dynamic, Standard, Cinema, Blackboard
	Cooling time	0s
	Auto Ceiling	Yes
	D-Zoom	±5
Others	360° projection	Yes
Others	3D	Yes
Dimension&Weight
	MAX Dimensions (WxDxH mm)	460(W)355(D)142.6(H)
	Net. Weight (KG)	~10KG
	Packaging Size (WxDxH mm)	574(W)554(D)268(H)
	Gross. Weight (KG)	12.5kg
Accessories
	Standard Accessaries	Power cord, HDMI cable, Remote control
