7500 Lumens 4K 3LCD Laser Projector for Large Venue, Simulation & Immersive Projection | SMX

  • 7500 Lumens High Brightness
  • 4K UHD Resolution
  • 3LCD True Color Technology
  • Edge Blending & 360° Projection
  • Lens Shift & Keystone Correction
  • Short Throw & Flexible Installation
  • 20,000–30,000 Hours Laser Lifespan
Availability:
Quantity:
Inquire Add to Basket

  • MX-LK7500

  • SMX


4K 7500 Lumens  3LCD Laser Projector


High-brightness projector designed for large venues, immersive projection, and simulation environments.



Home-Cinema-Laser-Projector-7500-Lumen

7500 lumen laser projector


7500 Lumens 4K Laser Projector for Large Venues

The SMX MX-LK7500 delivers 7500 lumens of high brightness with 4K UHD resolution and 3LCD true color technology, perfect for immersive projection, simulation centers, and large venue installations.


Supports edge blending and 360° projection for seamless multi-projector setups, lens shift and keystone correction for flexible installation, and a long-lasting laser light source up to 30,000 hours.



Key Features

  • 7500 Lumens Brightness – Clear images in ambient light environments

  • 4K UHD Resolution – Ultra-sharp, detailed images

  • 3LCD Technology – Superior color brightness and accuracy

  • Edge Blending & 360° Projection – Perfect for immersive installations

  • Lens Shift & Keystone Correction – Flexible installation

  • Laser Light Source – Up to 30,000 hours lifespan



Applications


Specifications

Item Specification
Brightness 7500 Lumens
Resolution 4K UHD (3840×2160)
Display 3LCD
Contrast Ratio 5,000,000:1
Light Source Laser
Lifespan 20,000–30,000 Hours
Installation Edge Blending & 360° Flexible Mount


Related Solutions


Request Your Professional Projection Solution

Contact SMX for OEM/ODM services, pricing, and project consultation.

Get Quote

Download Spec Sheet




Model No.MX-LK7500
Key parts

Lens MakerZMAX Lens
Throw Ratio1.08(wide)-1.76(tele)
Zoom Ratio1.6X  Zoom
Light sourceNICHIA LASER
Brightness

Brightness7500Lumen
Overall Spec
PanelDisplay Panel3x0.64"  with MLA
Display TechnologyLiquid Crystal Display
Resolution4K Enhancement
Light source Life timeNormal mode20000hrs
ECO mode30000hrs
Projection LensLens VendorZMAX Lens
F1.58~2.02
f15.3mm-24.6mm
Zoom/FocusManual
Throw Ratio1.08(wide)-1.76(tele)
Zoom Ratio1.6
Screen size30-300  inch
Lens ShiftV:+0%~55%
H:±22%
CRContrast Ratio5000000:1
NoiseNoise(dB) 38dB(Normal)
30dB(ECO1)
28dB(ECO2)
UniformityUniformity-JBMA80%
ARAspect RatioCompatible: 4:3/16:10
Terminal(I/O port)
InputHDMI 2.1(IN)*2
USB-A*2
RJ45*1
HD BaseT*1(Optional)
RS232C*1
OutputAudio  portS/PDIF*1
Audio out
(mini jack,3.5mm)		*1
ControlRJ45*1  (Control)
General Spec
AudioSpeaker16W*1
Dust filterW/Filter
Filter Life time8000h
Power ConsumptionPower Requeirements100~240V@ 50/60Hz
Power Consumption
    (Normal) (Max)		435
Power Consumption
    (ECO)(Max)		240
ECO Standby Mode
    Power Consumption		<0.5W
Temp.&HumidityOperating   Temp.0   to 40°C
Operating Thumidity.20-85%
Store Temp. -10 to 50°C
High altitude0~3000m
Other Functions
KeystoneKeystone Correction
(Lens@center)

V: ±30°

H：±25°

4 Corner Correction
OSDLanguagesEnglish, Chinese,
LAN ControlLAN Control-- PJ LinkYes
Scanning FrequencyH-Synch Range15~100KHz
V-Synch Range24~85Hz
Display ResolutionVideo Signal Inputup to 3840x2160/60Hz

Voice controlNear-field RC voice
BluetoothBluetooth Version 5.0
Wireless Projection FunctionOptional
lamp modeNormal/ECO
Light source brightness50-100%
High altitudeYes
Auto CeilingYes
HDR10Support
360° free viewingSupport
Standby modeEnergy-efficient
Dimension&Weight

MAX Dimensions
(WxDxH mm)		405 (W)*358(D)*137(H)
Net. Weight (KG)~7.9KG
Packaging Box Dimensions
(WxDxH mm)		510(W)*498(D)*260(H)
Gross. Weight (KG)~10.4KG
Accessory

Manual LanguagesChinese,English
Standard AccessariesPower Cord,Remote control
download SMX 7500 Lumen 4K Laser Projector Specification.pdf
