6500 Lumen 3LCD Laser Projector WXGA | Multi-Channel Projection & Installation Projector

  • 6500 Lumens High Brightness
  • WXGA Resolution
  • 3LCD True Color Technology
  • 4K Input Compatible (HDMI)
  • 5,000,000:1 Dynamic Contrast
  • 360° Projection & Geometry Correction
  • 20,000–30,000 Hours Laser Lifespan
Availability:
Quantity:
Inquire Add to Basket

  • MX-VL650W

  • SMX

6500 Lumen WXGA 3LCD Laser Projector for Multi-Channel Projection

Bright. Reliable. Installation-Ready.

Deliver stunning visuals with this high-performance 6500 lumen 3LCD laser projector. Designed for professional installations, multi-channel projection setups, and large venues, it ensures vivid color accuracy, flexible installation, and long-lasting performance.

Key Features

6500 Lumens High Brightness

Crystal-clear images even in bright environments such as classrooms and conference rooms.

3LCD True Color Technology

Accurate and vibrant color reproduction without rainbow effect, ideal for professional presentations.

WXGA Resolution

Optimized for business and education use with sharp and clear visuals.

Laser Light Source

Up to 30,000 hours lifespan with minimal maintenance and stable brightness.

Multi-Channel Projection Support

Perfect for projection mapping, blending, and immersive visual installations.

Flexible Installation

Supports lens shift, 360° installation, and multiple mounting options.

6500 lumen laser projector wxga.webp

Applications

Conference Rooms

Enhance business meetings with bright and clear presentations.

Education

Ideal for classrooms and lecture halls with consistent performance.

Large Venues

Perfect for auditoriums, churches, and event spaces.

Projection Mapping

Supports multi-channel edge blending and immersive experiences.

Why Choose This Projector

  • High brightness suitable for large environments

  • Low maintenance laser technology

  • Superior color performance vs traditional DLP

  • Professional-grade installation flexibility

  • Reliable for 24/7 commercial usage

Technical Specifications

Brightness

6500 Lumens

Display Technology

3LCD

Resolution

WXGA (1280x800)

Light Source

Laser

Light Source Life

Up to 30,000 hours

Contrast Ratio

High Contrast Performance

Installation

360° Flexible Installation

Application

Business, Education, Large Venue

OEM & ODM Services

We are a professional projector manufacturer offering OEM and ODM services for global brands. With stable production capacity and strict quality control, we support bulk orders and customization requirements.

  • 6 Production Lines

  • 15,000 Units Monthly Capacity

  • Short Lead Time

  • Customized Branding Available

Get a Quote

Looking for a reliable projector supplier? Contact us today for pricing, customization, and technical support.

Contact us

ModelMX-VL650W

Brightness  Lumen6500
Native ResolutionWXGA (1280 x 800)
Overall Spec
PanelDisplay Panel3x0.64" with MLA
Display TechnologyLiquid Crystal Display
Native ResolutionWXGA (1280 x 800)
Light source
Life time		FullNormal/Normal mode 20000hrs
ECO1 mode 30000hrs
ECO2 mode30000hrs
Projection LensLens VendorFujifilm Lens
F1.7~2.21
f17.42~28.99mm
Zoom/FocusManual
Throw Ratio1.3(wide)-2.2(tele)
Zoom Ratio1.66
Screen size30-300  inch
Lens Shift V:＋55%～0%、H:±26%
CRContrast Ratio5000000:1
NoiseNoise(dB)38dB (Normal)
30dB (ECO1)
28dB (ECO2)
ARAspect RatioNative:16:1 Compatible: 4:3/16:9
Terminal(I/O  port)
InputVGA*1
HDMI 1.4B(IN)*2
USB-A*1
USB-B*1(Display)
RJ45*1(Display)
HD BaseT*1(Optional)
Audio in
    (mini jack,3.5mm)		*1
OutputVGA*1
Audio out
    (mini-jack,3.5mm)		*1
ControlRS232*1
RJ45*1(Control)
USB-B*1(For upgrade)
General Spec
AudioSpeaker16W*1
Power ConsumptionPower Requirements100~240V@ 50/60Hz
Power Consumption
    (Normal) (Max)		350
Power Consumption
    (ECO1) (Max)		270
Power Consumption
    (ECO2) (Max)		230
ECO Standby Mode
    Power Consumption		<0.5W
Other Functions
KeystoneKeystone   Correction
    (Lens@center)		V:   ±30°
H：±30°
Pincushion/Barrel Correction
6 Corner Geometry correction
4 Corner Correction
Grid image tune
LAN ControlLAN   Control-RoomView
(Crestron)		Yes
LAN Control-- AMX DiscoveryYes
LAN Control-- PJ Link Yes
Scanning FrequencyH-Synch Range15~100KHz
V-Synch Range24~85Hz
Others 360°   projectionYes
Dimension&Weight

MAX Dimensions
    (WxDxH mm)		405(W)*358(D)*137(H)
Net. Weight (KG)~7.7KG
Packaging Box Dimensions
    (WxDxH mm)		510(W)*498(D)*260(H)
Gross. Weight (KG)~10.2KG
Accessory

Manual   LanguagesChinese, English
Standard AccessariesPower cord, Remote control, HDMI Cable


download SMX 6500-7200 Lumen 3LCD Laser Projector Catalog.pdf

download SMX 6500-7200 Lumen Laser Projector Specification.pdf
