6000 Lumens WXGA 3LCD Laser Short Throw Projector | SMX SL6000W

6000 lumens WXGA 3LCD laser short throw projector with 0.44:1 ratio, ideal for immersive and education use.6000 lumens WXGA 3LCD laser short throw projector with 0.44:1 ratio, ideal for immersive and education use.

6000 Lumens High Brightness
WXGA 1280×800 Resolution
0.44:1 Short Throw Ratio
3LCD Color Technology
20,000 Hours Laser Life

Availability:

Quantity:



Inquire Add to Basket

Model:
MX-SL6000W
Brand:
SMX

6000 Lumens WXGA 3LCD Laser Short Throw Projector

Reliable short throw projector for immersive projection and education environments.

✔ 6000 Lumens High Brightness
✔ WXGA 1280×800 Resolution
✔ 0.44:1 Short Throw Ratio
✔ 3LCD True Color Technology
✔ 20,000 Hours Laser Lifespan

Professional 6000 Lumen WXGA Short Throw Projector

The SMX SL6000W is a 6000 lumens WXGA 3LCD laser projector designed for immersive wall projection, classrooms, and business applications. Its short throw ratio of 0.44:1 allows large image projection in limited spaces, reducing shadows and improving user interaction.

With advanced 3LCD technology and a long-life laser light source, this projector ensures stable brightness, accurate colors, and low maintenance operation.

Key Features

6000 Lumens Brightness – Clear visuals in ambient light
WXGA Resolution – Optimized for education and presentations
Short Throw 0.44:1 – Large screen at short distance
3LCD Technology – Superior color brightness
Laser Light Source – 20,000 hours lifespan

Applications

Immersive wall projection
Classrooms & education
Interactive learning environments
Museums & exhibitions
Meeting rooms

Specifications

Item	Specification
Brightness	6000 Lumens
Resolution	WXGA (1280×800)
Display	3LCD
Light Source	Laser
Throw Ratio	0.44:1
Contrast Ratio	5,000,000:1
Lifespan	20,000 Hours
Screen Size	55–300 inch

Why Choose a WXGA Short Throw Projector?

WXGA projectors provide an excellent balance between performance and cost, making them ideal for education and business environments. Combined with short throw design, they enable flexible installation and reduce shadow interference.

For immersive projection and interactive applications, a 6000 lumen short throw projector delivers the brightness and clarity required.

Related Guides

Looking for a Reliable Short Throw Projector?

Contact SMX for pricing, OEM services, and technical support.

Get Quote
Browse More Projectors

2Model	MX-SL6000W
	Brightness(Lumen)	6000
Overall Spec
Panel	Display Panel	3x0.64” with MLA
	Display Technology	Liquid Crystal Display
	Native Resolution	WXGA (1280 x 800)
Light source Life time	Normal mode	20000hrs
Light source Life time	ECO1 mode	30000hrs
Lens	Lens Vendor	RICOH
Projection Lens	F	F1.6
	f	6.39mm
	Zoom/Focus	Manual
	Throw Ratio	0.44:1
	Screen size	55-300inch
CR	Contrast Ratio (FOFO)	5000000:1
Noise	Noise(dB)	37dB (Normal) / 27dB (ECO)
Uniformity	Uniformity(Actual Min) -JISX6911	80%
AR	Aspect Ratio	Native:16:10 / Compatible: 4:3/16:9
Terminal(I/O port)
Input	VGA	*1
	HDMI 1.4B(IN)	*2
	USB-A	*1
	USB-B	*1(Display)
	RJ45	*1 (Display)
	HD BaseT	*1 (Optional)
	Audio in (mini jack,3.5mm)	*1
Output	VGA	*1
Output	Audio out (mini-jack,3.5mm)	*1
Control	RS232	*1
	RJ45	*1 (Control)
	USB-B	*1 (For upgrade)
General Spec
Audio	Speaker	16W*1
Dust filter		W/Filter
Filter Life time		8000h
Power Consumption	Power Requeirements	100~240V@ 50/60Hz
	Power Consumption (Normal) (Max)	350
	Power Consumption (ECO1) (Max)	270
	Power Consumption (ECO2) (Max)	230
	ECO Standby Mode Power Consumption	<0.5W
Temp.&Humidity	Operating Temp.	0 to 40°C
	Operating Thumidity.	20-80%
	Store Temp.	-10 to 50°C
	High altitude	0~3000m
Other Functions
Keystone	Keystone Correction （Lens@center)	V: ±15° H：±15° Pincushion/Barrel Correction 6 Corner correction 4 Corner Correction Grid image tune
OSD	Languages	26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi
LAN Control	LAN Control-RoomView (Crestron)	Yes
	LAN Control-- AMX Discovery	Yes
	LAN Control-- PJ Link	Yes
Scanning Frequency	H-Synch Range	15~100KHz
Scanning Frequency	V-Synch Range	24~85Hz
Display Resolution	Computer Signal Input	VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz
Display Resolution	Video Signal Input	480i, 480p, 576i, 576p, 720p, 1080i and 1080p
SW setting	Auto Setup	INPUT SEARCH,AUTO PC,Auto Keystone
	Blank	Yes
	Suspend	Yes(5miniutes no singnal as default)
	Picture mode	Dynamic, Standard, Cinema, Colorboard, sim-DICOM, Blackboard(Green)
	Cooling time	0s, Normal,30s
	Closed caption	N/A
	Auto Ceiling	Yes
	D-Zoom	1~33
Others	360° Projection	Yes
Dimension&Weight
	MAX Dimensions (WxHxD mm)	405(W)×404(D)×164(H)
	Net. Weight (KG)	8.1kg
	Packaging (WxHxD mm)	510(W)×498(D)×260(H)
	Gross. Weight (KG)	~10.4KG
Accessory
	Manual Languages	Chinese,English
	Standard Accessaries	Power cord (EU)/power cord (Ja), Remote control
