5200 Lumens 4K 3LCD Laser Projector for Home Theater & Immersive Projection | SMX

  • 5200 Lumens High Brightness
  • 4K UHD Resolution
  • 3LCD True Color Technology
  • 5,000,000:1 High Contrast
  • Flexible Lens & Zoom (1.2x)
  • 30–300 Inch Projection
  • 20,000–30,000 Hours Laser Lifespan
Availability:
Quantity:
Inquire Add to Basket

  • MX-LK5200

  • SMX

5200 Lumens 4K 3LCD Laser Projector for Home Theater & Immersive Projection | SMX

Designed for home theater, immersive projection, and premium AV experiences.

5200 Lumens 4K Laser Projector.webp

5200 Lumens 4K Home Theater Laser Projector

The SMX MX-LK5200 delivers stunning 4K resolution with 5200 lumens brightness, designed for home cinema, immersive projection, and entertainment environments.

With high contrast ratio and 3LCD technology, it produces vivid colors and sharp images even in ambient lighting conditions, creating a cinema-level viewing experience at home.

Key Features

  • 5200 Lumens Brightness – Clear images even in bright rooms

  • 4K UHD Resolution – Ultra detailed visuals

  • 3LCD Technology – Superior color brightness (Learn More)

  • High Contrast 5,000,000:1 – Deep blacks and vivid highlights

  • Flexible Installation – Lens shift and zoom (1.2x optics)

  • Laser Light Source – Up to 30,000 hours lifespan

Applications

4k home cinema projector.webp

Specifications

Item

Specification

Brightness

5200 Lumens

Resolution

4K UHD

Display

3LCD

Contrast Ratio

5,000,000:1

Throw Ratio

1.35–1.63:1

Zoom

1.2x Optical

Screen Size

30–300 inch

Light Source

Laser

Lifespan

20,000–30,000 Hours

Upgrade Your Home Cinema Experience

Contact SMX for pricing, OEM/ODM services, and project solutions.

Get Quote

Download Spec Sheet

OEM Project

Main Specification

Model No.MX-LK5200
Brightness (Lumen)5200
Resolution4K
Overall Spec
PanelDisplay Panel3x0.64" with MLA
Display TechnologyLiquid Crystal Display
Light source LifetimeLight SourceLaser
Normal mode20000hrs

ECO mode

30000hrs
Projection LensLens VendorZmax  Lens
F1.61~1.76
f19.1~23mm
Zoom/FocusManual
Throw Ratio1.35~1.63:   1
Zoom Ratio1.2x optics
Screen size30-300inch
CRDynamic Contrast Ratio5,000,000:1
NoiseNoise(dB)40dB(Normal)
 30dB(ECO)
UniformityUniformity80%
ARAspect RatioNative:16:9
Compatible: 4:3/16:10
Terminal(I/O port)
InputHDMI  (2.0IN)*2
USB-A*2
RJ45*1
HD BaseT*1(Optional)
OutputAudio portS/PDIF*1
Audio out
(mini-jack,3.5mm）		*1
ControlRS232C*1
RJ45*1   (Control)
General Spec
AudioSpeaker16W*1
Dust filterW/Filter
Filter Lifetime7000h
Power ConsumptionPower Requeirements100~240V@ 50/60Hz
Power Consumption
(Normal) (Max)		330
Power Consumption
(ECO1) (Max)		190
ECO Standby Mode
Power Consumption		<0.5W
Temp.&HumidityOperating Temp.0 to 40°C
Operating humidity.20-80%
Storage Temp. -10 to 50°C
Storage humidity.10-85%
High altitude0-3000m
Other Functions
KeystoneKeystone Correction
(Lens@center)		V: ±30° H：±25°
4 Corner Correction
OSDLanguagesEnglish, Simplified Chinese
LAN ControlLAN Control--PJ LinkYes
Scanning FrequencyH-Synch Range15~100KHz
V-Synch Range24~85Hz
Display ResolutionComputer Signal Inputup to 4K60Hz
SW settingD-ZoomYES（HDMI）
laser modeNormal/ECO
Light source
brightness adjustment		50-100%
High altitudeYes
Auto CeilingYes
HDR10Yes
Standby modeNormal/ECO
Others360° projectionYes
Dimension&Weight

Product
(WxDxH mm)		390*294*128
Net. Weight (KG)5Kg
Packaging
(WxDxH mm)		492*443*239
Gross. Weight (KG)~6.5Kg
Accessory

Manual LanguagesChinese,English
Standard AccessariesPower cord  Remote control,HDMI Cable


download SMX 4800 -5200 Lumen Long Throw 4K Laser Projector Catalog.pdf

download SMX 4800-5200 lumen 4K Laser Projector Specification.pdf
