MX-STD4800W
SMX
The SMX MX-STD4800W delivers 4800 ANSI lumens of brightness, providing clear and bright projection for classrooms, meeting rooms, training facilities and professional presentation environments.
Combining a laser light source with 3LCD projection technology, this WXGA laser projector is designed to display educational materials, business presentations, charts and multimedia content in a variety of commercial environments.
The SMX MX-STD4800W features native WXGA resolution with a 16:10 widescreen aspect ratio, making it suitable for classroom teaching, business presentations and multimedia display applications.
The projector supports compatible computer input signals including WUXGA and 4K@30Hz. These signals are processed for display at the projector's native WXGA resolution, allowing flexible connection to different presentation sources.
The MX-STD4800W uses 3LCD technology with a laser light source to deliver colorful projected images for business, education and professional presentation applications.
By processing red, green and blue light through separate LCD panels, 3LCD technology creates full-color images suitable for presentation graphics, educational diagrams, videos and multimedia materials.
Separate red, green and blue image processing.
Suitable for colorful charts and multimedia presentations.
Designed for business and educational visual communication.
The SMX MX-STD4800W features a laser light source designed for extended operation and reduced routine lamp replacement requirements.
The light source is rated for 20,000 hours in Normal mode. The product specification also lists 30,000 hours in ECO1 mode as a preliminary value requiring final confirmation.
*The ECO1 lifetime is marked TBD in the product specification and is subject to final confirmation.
The SMX MX-STD4800W offers a dynamic contrast ratio of 5,000,000:1, helping distinguish bright and dark areas in projected images.
Combined with 4800 ANSI lumens brightness and 3LCD laser projection technology, the projector supports the presentation of business graphics, classroom videos, educational diagrams and other multimedia content.
The MX-STD4800W features a RICOH projection lens with a 1.48-1.78:1 standard throw ratio and 1.2x optical zoom, providing installation flexibility for classrooms, business meeting rooms and training facilities.
Manual zoom and focus allow users to fine-tune image size and sharpness according to the installation distance. The projector supports screen sizes ranging from 30 to 300 inches, making it suitable for various professional display requirements.
The SMX MX-STD4800W supports horizontal and vertical keystone correction of +/-30 degrees together with four-corner adjustment, helping installers align the projected image with the screen.
These correction functions are particularly useful for classrooms, conference rooms and training environments where the projector cannot always be installed directly in front of the screen.
Adjust vertical trapezoidal image distortion.
Correct horizontal image alignment.
Fine-tune the four image corners independently.
Automatic keystone function for convenient setup.
The MX-STD4800W supports 360-degree projection installation, allowing flexible mounting orientations for different professional projection environments.
Combined with automatic ceiling orientation and keystone correction functions, the projector can accommodate a variety of classroom, training room and commercial AV installation requirements.
The SMX MX-STD4800W offers multiple input, output and control interfaces for connecting computers, presentation equipment, audio systems and compatible professional AV devices.
Dual HDMI inputs, VGA connectivity, USB interfaces and LAN control functions provide flexibility for classroom teaching, business presentations and commercial installations.
Digital video inputs for compatible presentation equipment.
Analog computer connectivity.
USB connections for supported display and control functions.
Network display and control connectivity.
External control interface for compatible AV systems.
Audio inputs, audio output and video input.
The MX-STD4800W supports network-based projector control, making it suitable for integration into compatible educational and business AV management environments.
Support for Crestron RoomView, AMX Discovery and PJLink provides flexible options for projector monitoring and control through compatible network systems.
Supported network control integration for compatible Crestron systems.
Compatibility with supported AMX device discovery functions.
Network projector control protocol support for compatible AV systems.
The SMX MX-STD4800W features a built-in 16W speaker, providing integrated audio playback for classroom presentations, teaching materials and business multimedia demonstrations.
With operating noise levels of 37dB in Normal mode and 27dB in ECO1 mode, the projector provides a quieter operating option for professional presentation environments.
The SMX MX-STD4800W combines 4800 ANSI lumens brightness, WXGA resolution, 3LCD laser technology and flexible installation features to support different professional projection requirements.
Suitable for teaching materials, educational videos and classroom presentations.
Provides projection for lectures, seminars and educational presentations.
Supports presentation slides, business charts and multimedia content.
Offers reliable projection for workshops, training sessions and professional learning.
Contact SMX to explore the MX-STD4800W, discuss your projection requirements and request product specifications, pricing and OEM/ODM cooperation information.
Explore the technical specifications of the SMX 4800 ANSI lumens WXGA 3LCD standard throw laser projector.
| Display and Optical System | |
|---|---|
| Model | MX-STD4800W |
| Brightness | 4800 ANSI Lumens |
| Native Resolution | WXGA |
| Display Technology | 3LCD |
| Light Source | Laser |
| Laser Life (Normal) | 20,000 Hours |
| Laser Life (ECO1) | 30,000 Hours (TBD) |
| Dynamic Contrast Ratio | 5,000,000:1 |
| Lens Vendor | RICOH |
| Lens F Number | 1.6-1.76 |
| Focal Length | 19.158-23.018 mm |
| Zoom / Focus | Manual |
| Throw Ratio | 1.48-1.78:1 |
| Optical Zoom | 1.2x |
| Projection Screen Size | 30-300 Inches |
| Aspect Ratio | 16:10 Standard / 4:3 Compatible |
| Uniformity | 80% |
| Installation and Features | |
| Keystone Correction | Vertical +/-30 Degrees / Horizontal +/-30 Degrees |
| Corner Correction | 4-Corner Correction |
| 360-Degree Projection | Supported |
| Auto Ceiling | Supported |
| Auto Setup | Input Search, Auto PC, Auto Keystone |
| Picture Modes | Dynamic, Standard, Cinema, Colorboard, Blackboard (Green) |
| Digital Zoom | 1-19 |
| Computer Signal Input | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, 4K@30Hz |
| Video Signal Input | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| OSD Languages | 26 Languages |
| Wireless Display | Optional, with compatible accessories |
| Connectivity and Control | |
| HDMI Input | 2 |
| VGA Input / Output | 1 / 1 |
| Video Input | 1 |
| Audio Input | 3.5 mm Mini Jack x 1; RCA L/R x 1 Set |
| Audio Output | 3.5 mm Mini Jack x 1 |
| USB-A | 1 |
| USB-B | Display / Control Functions |
| RJ45 / LAN | Display / Control Functions |
| RS-232 | 1 |
| LAN Control | Crestron RoomView, AMX Discovery, PJLink |
| General Specifications | |
| Built-in Speaker | 16W x 1 |
| Noise Level | 37dB Normal / 27dB ECO1 |
| Dust Filter | With Filter |
| Filter Lifetime | 7,300 Hours (TBD) |
| Power Requirements | 100-240V AC, 50/60Hz |
| Normal Power (Max) | 270W |
| ECO1 Power (Max) | 175W |
| ECO2 Power (Max) | 155W |
| ECO Standby Power | Less Than 0.5W |
| Operating Temperature | 5-40 Degrees C |
| Operating Humidity | 20-80% |
| High Altitude | 1700-3000 m |
| Product Dimensions | 390 x 294 x 127 mm (W x D x H) |
| Net Weight | 5 kg |
| Packing Dimensions | 492 x 443 x 239 mm |
| Gross Weight | Approx. 6.5 kg |
| Standard Accessories | Power Cord, Remote Control, HDMI Cable, Quick Start Guide |
Note: ECO1 laser lifetime and filter lifetime are marked TBD in the product specification. Specifications are subject to final confirmation.
Find answers to common questions about the SMX MX-STD4800W 4800 ANSI lumens WXGA 3LCD laser projector.
The SMX MX-STD4800W delivers 4800 ANSI lumens of brightness, making it suitable for classrooms, meeting rooms, training facilities and business presentations.
The projector features native WXGA resolution with a 16:10 aspect ratio. It accepts compatible WUXGA and 4K@30Hz computer signals, but its native display resolution remains WXGA.
The laser light source is rated for 20,000 hours in Normal mode. The specification lists 30,000 hours in ECO1 mode as a preliminary value subject to final confirmation.
The MX-STD4800W features a 1.48-1.78:1 standard throw ratio, 1.2x optical zoom and manual focus. It supports projection screen sizes from 30 to 300 inches.
Yes. It supports vertical and horizontal keystone correction of +/-30 degrees together with 4-corner correction for flexible image alignment.
Yes. The MX-STD4800W supports 360-degree projection installation and automatic ceiling orientation for flexible professional mounting configurations.
The projector includes two HDMI inputs, VGA input and output, video input, USB-A, USB-B, RJ45/LAN, RS-232C and audio connections for compatible AV equipment.
Yes. The MX-STD4800W supports Crestron RoomView, AMX Discovery and PJLink for integration with compatible AV control systems.
Yes. The projector features an integrated 16W speaker. Its specified operating noise level is 37dB in Normal mode and 27dB in ECO1 mode.
Wireless display is an optional function. Supported connection methods depend on the selected configuration and compatible wireless accessories. Please contact SMX to confirm the available wireless options.
