MX-407W
SMX
✔ 4300 Lumens Business Brightness
✔ WXGA 1280×800 Widescreen Resolution
✔ 3LCD Vivid Color Projection
✔ Hybrid Workspace Optimized
✔ Modern Office Collaboration Solution
The SMX 4300 lumens WXGA 3LCD projector is designed for hybrid workspaces, office collaboration areas, seminar rooms, and business communication environments. Combining widescreen WXGA resolution with vivid 3LCD technology, it delivers immersive and professional multimedia presentations for modern office teams.
4300 Lumens High-Brightness Projection
WXGA 1280×800 Widescreen Resolution
3LCD True Color Display Technology
Optimized for Hybrid Office Spaces
Wireless Presentation Compatibility
Large Screen Collaboration Capability
HDMI Multimedia Connectivity
Flexible Installation Deployment
Stable Long-Term Commercial Operation
Designed for Business Communication
The projector is developed for modern business collaboration spaces, hybrid work environments, and communication-focused office applications requiring reliable widescreen projection performance.
4300 lumens brightness ensures clear visibility for presentations, spreadsheets, video conferencing, and multimedia content in office environments with ambient lighting.
WXGA 1280×800 resolution supports widescreen office applications, presentation slides, Excel documents, Teams meetings, and modern business communication platforms.
3LCD projection technology delivers vivid color reproduction and balanced image quality for collaborative presentations and multimedia business communication.
HDMI and multimedia interfaces support laptops, wireless presentation systems, conferencing platforms, and enterprise AV integration.
Large-format projection capability improves collaboration efficiency during brainstorming sessions, project reviews, training activities, and team discussions.
Designed for long-term business operation, the projector provides stable performance and reduced maintenance requirements for enterprise users.
Hybrid Workspace
Office Collaboration Space
Wireless Presentation Area
Business Communication Room
Corporate Seminar Space
Team Collaboration Environment
Modern Office AV System
Commercial Multimedia Space
Brightness | 4300 Lumens |
Resolution | WXGA 1280×800 |
Display Technology | 3LCD |
Aspect Ratio | 16:10 Widescreen |
Connectivity | HDMI / VGA / USB / Audio |
Projection Size | 40-300 Inches |
Applications | Hybrid Office / Collaboration / Business |
Professional OEM & ODM Projection Factory
Commercial AV Integration Experience
Business Projection Solution Expertise
Global Enterprise Projection Projects
Strict Commercial Quality Standards
Reliable Long-Term Operation
Yes. The projector is optimized for hybrid office collaboration and modern business communication environments.
WXGA widescreen resolution better supports spreadsheets, presentation slides, video conferencing, and modern office applications.
Yes. The projector is compatible with wireless presentation systems and enterprise AV integration.
Yes. 4300 lumens provides clear visibility in medium-sized business collaboration spaces with ambient lighting.
| Main Spec | ||
| Model No. | MX-407W | |
| Resolution | 4300 | |
| Resolution | WXGA | |
| Light source | Lamp:240W | |
| Overall Spec | ||
| Panel | Display Panel | 3x0.59” |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | WXGA (1280 x 800) | |
| Lamp | Lamp Consumption(W) | signify:240W Infinity(Lamp) |
| Lamp Lifetime(H) | 10000H(Normal) /20000H(ECO) | |
| Projection Lens | Zoom/Focus | Manual |
| Throw Ratio | 60"@1.88m ; 1.46~1.76 :1 | |
| F | 1.61~1.76 | |
| f | 19.1~23mm | |
| Zoom Ratio | 1.2x optics | |
| Screen size | 0.927~11.504m (30"~300") | |
| CR | IRIS | *1 |
| Contrast Ratio | 15000:1 | |
| Noise | Noise(dB)@1m | Normal: 38dB ECO1: 34dB; ECO2:28dB |
| Uniformity | Uniformity | 80% |
| AR | Aspect Ratio | 16:10 (Standard)/ 4:3(Compatible) |
| Terminal(I/O port) | ||
| Input | VGA | *1 |
| HDMI | *2 | |
| Video | *1 | |
| Audio in (mini jack,3.5mm ) | *1 | |
| Audio in (RCA×2) <Audio L/R> | *1 | |
| USB-A | *1 | |
| USB-B | *1(Display) | |
| RJ45 | *1(Display) | |
| Output | VGA | *1 |
| Audio out (mini-jack,3.5mm ) | *1 | |
| Control | RS232 | *1 |
| RJ45 | *1 (Control) | |
| USB-B | *1 | |
| LAN | *1 | |
| General Spec | ||
| Audio | Speaker | 1*16W |
| Power Consumption | Power Requeirements | 100~240V@ 50/60Hz |
| Power consumption (W) | 340 | |
| Power Consumption (ECO) | 150 | |
| ECO Standby Mode Power Consumption | <0.5W | |
| Network standby Power Consumption | <2W | |
| Cooling Setting | Operating Temp. | 5°C~40°C(35~ ECO) |
| Store Temp. | -10℃~~50℃ | |
| Oparating Humidity | 20%~80% | |
| High altitude | 0 to 3000 m | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30°/ H:±30° 4 corner Correction |
| LAN Control | LAN Control-RoomView (Crestron) | Yes |
| LAN Control-AMX Discovery | Yes | |
| LAN Control-PJ Link | Yes | |
| SW setting | Auto Setup | INPUT SEARCH,AUTO PC, AUTO Keystone |
| Auto Ceiling | Yes | |
| Dimension&Weight | ||
| MAX Dimensions (WxHxD mm) | 345*261*99 | |
| Net. Weight (KG) | ~3.3 | |
| Packaging Size (WxHxD mm) | 442*386*195 | |
| Gross. Weight (KG) | 4.7 | |
| Accessory | ||
| Standard Accessaries | Power cord, HDMI cable, Remote control | |
