MX-L3300XT
SMX
The SMX MX-L3300XT is a high-performance 3LCD short throw projector designed for education, business meetings, and professional presentations. It delivers bright, accurate, and stable images even in well-lit environments.
3300 Lumens Brightness – Clear in ambient light
3LCD Technology – Natural & accurate colors
Short Throw Design – Big image in small space
Stable XGA Resolution – Reliable for business use
Long Lamp Life – Low maintenance cost
3LCD technology uses three separate LCD panels for red, green, and blue light, delivering smoother images, better color accuracy, and eliminating rainbow effects commonly found in DLP projectors.
Perfect for classrooms, training rooms, and interactive learning environments.
Ideal for meetings, presentations, and corporate communication.
Short throw design allows large projection even in limited rooms.
Brightness: 3300 Lumens
Display Technology: 3LCD
Resolution: XGA
Throw Ratio: Short Throw
Light Source Life: Long-lasting lamp
Factory Direct Manufacturer
OEM / ODM Support
Stable Quality Control System
Global Export Experience
Fast Delivery Capability
It can project a large image from a short distance, ideal for small rooms.
Yes, it is suitable for classrooms and office environments with controlled lighting.
It uses three LCD panels to produce accurate and stable RGB color images.
Contact us for wholesale pricing, customization, and global distribution support.
| Main Specification | ||
| Model No. | MX-L3300XT | |
| Brightness(Lumen) | 3300 | |
| Optical Data | ||
| Panel | Display Panel | 3x0.63” |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | XGA (1024x768) | |
| Lamp | Lamp Consumption(W) | Philips:218W |
| Lamp Lifetime(H) | 4000H(Normal) /10000H(ECO) | |
| Projection Lens | Zoom/Focus | Manual |
| Throw Ratio | 80"@0.75m; 0.46 : 1 | |
| F | F=1.8 | |
| f | f=6.08mm | |
| Zoom Ratio | N/A | |
| Screen size | 0.455~0.943m(50"~100") | |
| CR | Contrast Ratio(Min) | 10000:1(with Saver mode) |
| Noise | Noise(dB)@1m | ECO: MAX 34.9dB; Normal: 38.9dB |
| Uniformity | Uniformity | 80% |
| AR | Aspect Ratio | 4:3 (Standard)/16:9(Compatible) |
| Terminal (I/O port) | ||
| Input | VGA | *1 |
| YCbCr/Component | *1(share with VGA in 1) | |
| Video | *1 | |
| S-Video | *1(share with VGA in1) | |
| HDMI | *1 | |
| Output | VGA | *1 |
| Control | RS232 | *1 |
| General Spec | ||
| Audio | Speaker | N/A |
| Power Consumption | Power Requirements | 100~240V@ 50/60Hz |
| Power Consumption | 270W | |
| ECO Standby Mode Power Consumption | <0.5W | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±15°(manual) |
| OSD | Languages | 26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazakh, Vietnamese, Thai, Farsi |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 48~85Hz | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,Mac, |
| Video Signal Input | PAL, SECAM, NTSC 4.43, PAL-M, PAL-N, PAL-60, 480i, 480p, 576i, 576p, 720p, 1080p and 1080i | |
| Dimension&Weight | ||
| MAX Dimensions (WxHxD mm) | 347*341*141 | |
| Net. Weight (KG) | 4 | |
| Packaging Size (WxHxD mm) | 463*458*211 | |
| Gross. Weight (KG) | 5.5 | |
| Accessory | ||
| Manual Languages | Chinese, English, Korean | |
| Standard Accessaries | Power cord, HDMI cable,R emote control | |
