6500 Lumens XGA 3LCD Projector for Meeting Room & Education | SMX

6500 Lumens High Brightness

XGA Resolution 1024x768

3LCD Technology True Color Display

High Color Brightness Clear Text & Graphics

Easy Installation Flexible Setup

Reliable Performance Idea for Daily Use

Availability:

Quantity:



Inquire Add to Basket

Model:
MX-LS6500X
Brand:
SMX

6500 Lumens XGA 3LCD Projector for Meeting Room & Education | SMX

Reliable and bright projection solution for meeting rooms, classrooms, and business presentations.

6500 Lumens Projector for Meeting Room & Education

The SMX 6500 lumens XGA 3LCD projector is designed for meeting rooms, classrooms, and business presentations. It delivers bright and vivid images with excellent color accuracy, ensuring clear text and graphics even in well-lit environments.

With reliable performance and cost-effective operation, this projector is ideal for daily use in education and corporate environments.

Why Choose 3LCD Projectors?

3LCD projector technology provides higher color brightness and more natural color reproduction, making it ideal for presentations, teaching, and business environments.

Higher Color Brightness
Natural Color Reproduction
Smooth Image Quality
No Rainbow Effect
Ideal for Text and Data Display

Applications of 6500 Lumens Projector

Meeting Rooms & Conference Rooms
Classrooms & Education
Training Centers
Corporate Presentations
Small Auditoriums

6500 lumen 3lcd projector for conference

Key Features

6500 lumens brightness for clear projection
XGA resolution for business and education use
3LCD technology for vivid colors
Stable performance for daily operation
Easy installation and setup

Technical Specifications

Item	Specification
Brightness	6500 Lumens
Resolution	XGA (1024×768)
Display Technology	3LCD
Light Source	Lamp
Contrast Ratio	High Contrast
Installation	Flexible Installation

FAQ

Is a 6500 lumens projector suitable for meeting rooms?

Yes, it is ideal for medium to large meeting rooms with ambient light.

Why choose a 3LCD projector?

3LCD projectors provide better color brightness and more natural image quality, especially for presentations.

Is XGA resolution enough for business use?

Yes, XGA resolution is widely used for presentations, spreadsheets, and classroom teaching.

Looking for a Reliable Meeting Room Projector?

Contact SMX for pricing, OEM services, and professional projection solutions.

Get Quote

Catalog Download

Key Parts
	Model No.	MX-LS6500X
	Birghtness	6500
	Resolution	XGA (1024x768)
Overall Spec
Panel	Display Panel	3x0.63”
	Display Technology	Liquid Crystal Display
	Native Resolution	XGA (1024x768)
Lamp	Lamp Consumption(W)	USHIO:300W
Lamp	Lamp Lifetime(H)	3000H(Normal) /4000H(ECO)
Projection Lens	Zoom/Focus	Manual
	Throw Ratio	70"@1.653m 1.16-1.9
	F	F 1.6~1.9
	f	f= 15.31~24.64mm
	Zoom Ratio	1.6xoptics
	Screen size	0.691m~11.65m (30''~300")
	Lens Shift V	±40%(Manual)
	Lens Shift H	±10%(Manual)
CR	Contrast Ratio(Min)	10000:1
Noise	Noise(dB)@1m	ECO : MAX 35dB Normal : 41dB;
Uniformity	Uniformity	80%
AR	Aspect Ratio	4:3 (Standard)/16:9(Compatible)
Terminal (I/O port)
Input	VGA	*2
	Audio in (mini jack,3.5mm）	*1
	YCbCr/Component	*1(share with VGA in 1)
	Video	*1
	Audio in (L/R) --RCA	*2
	S-Video	*1(share with VGA in1)
	HDMI	*2(One is Compatible with MHL)
	USB- A	*1 1. Support Memeory viewer 2. WiFi Dongle (Optional Accessory)
	USB-B	*1(Display）
	RJ45	*1(Display）
Output	VGA	*1(Share with VGA IN 2)
Output	Audio out (mini-jack,3.5mm）	*1
Control	RS232	*1
	RJ45	*1 (Control)
	USB-B	*1(for up-grade)
General Spec
Audio	Speaker	1*10W
Power Consumption	Power Requeirements	100~240V@ 50/60Hz
	Power Consumption -Normal	~400W
	Power Consumption -ECO	~280W
	ECO Standby Mode Power Consumption	<0.5W
	Network standby Power Consumption	<3W
Temp.&Humidity	Operating Temp.	0℃~40℃(35~ ECO)
	Store Temp.	-20℃~~60℃
	Oparating Humidity	20%~85%
	Storage Humidity	10%~85%
Mechanical Design	Security bar	Yes
	Password protections	Yes
	Control Panel Lock	Yes
	Kenginston Lock	Yes
	Ventilation (In/Ex)	Side/Side
	Lamp access	Top
	Filter access	Side
	Dust filter	ESD filter
Accessory
Keystone	Keystone Correction	V: ±30°(auto+manual） H：±15°(manual） Pincushion/Barrel Correction Corner Keystone
OSD	Languages	26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korea, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi
LAN Control	LAN Control-RoomView (Crestron)	Yes
	LAN Control-AMX Discovery	Yes
	LAN Control-PJ Link	Yes
Scanning Frequency	H-Synch Range	15~91KHz
Scanning Frequency	V-Synch Range	24~85Hz
Display Resolution	Computer Signal Input	VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac
Display Resolution	Video Signal Input	PAL, SECAM, NTSC 4.43, PAL-M, PAL-N, PAL-60, 480i, 480p, 576i, 576p, 720p, 1080p and 1080i
Others	Auto Setup	INPUT SEARCH,AUTO PC AUTO Keystone
	Audio muting(Muting)	Yes
	Suspend	Yes(5miniutes no singnal as default)
	Picture mode	Dynamic Standard Cinema Blackboard Colorboard
	Lamp mode	NORMAL,ECO
	Filter Cleaning Cycle	100/200/300 hours
	Cooling time	0S,60s,90s
	Closed caption	Yes
	High altitude	Yes(1400~2700m)
	Signal Power On	Yes
	Turn on countdown	Customized-(0S, 10S, 30S..)
	Auto Ceiling	Yes
	D-Zoom	1~33
Dimension&Weight
	MAX Dimensions (WxHxD mm)	395318128
	Net. Weight (KG)	4.45
	Packaging Size (WxHxD mm)	495440230
	Gross. Weight (KG)	6
Accessory
	Manual Languages	Chinese,English
	Standard Accessaries	Power cord, HDMI cable,Remote control
